CUSTOM BODY CONSTRUCTION
Engineered and built to handle extreme Australian conditions.
CAPACITY
Our Escava Lamella Clarifier system is available in a 3 convenient standard models that can manage from 60 kL – 250 kL/day of work flow. Larger flows can be managed by using multiple units.
MODEL OPTIONS
Escava 150KL
- Flow rare: 150,000L/day
- Dimensions: 4,000 x 2,200 x 3,200mm (LxWxH)
- Inlet: DN80
- Outlet: DN100
- Sludge outlet: DN50
Escava 250KL
- Flow rare: 250,000L/day
- Dimensions: 4,000 x 2,200 x 3,200mm (LxWxH)
- Inlet: DN100
- Outlet: DN150
- Sludge outlet: DN80
SPECIFICATION
- Body: welded 304 stainless steel
- Support structure: 304 stainless steel
- Lamella separator plates: inclined, 100mm spacing
- Access stairs & inspection platform: galvanised steel and FRP grating
- Safety hand-rail: aluminum powder coated
- Lift points: certified lifting hooks
- Discharge pumps: duty/standby Grundfos discharge pumps
- Pump controller: easy access independent pump controls
- Skid: 304 stainless steel
- Control System: mining compliant MCC with Allen-Bradley PLC
- Control cabinet: lockable electrical & control cabinet
With body construction from epoxy coated steel, stainless steel or fibreglass, and manufactured to the highest standard of quality and workmanship, the Escava range will proven many years of reliable service.
Protex Water carries ISO certification for 9001 Quality, 14001 Environmental Management and 45001 for OH&S Management.
PERFORMANCE
This proven design allows continuous separation using two basic principles,
to increase the settling area, and to obtain a laminar flow. The lamella plate design creates a large effective settling area, while the incline provides the necessary laminar flow.
.
COMPLETELY PACKAGED
The Escava is packaged on a convenient skid system, with duty/standby Grundfos discharge pumps and an Allen-Bradley PLC. The system is pre-commissioned and can be easily lifted into place, providing quick and hassle-free installation.
Our Escava brand range of products helps screen, separate or compact sediments from wastewater, providing primary treatment for a host of industry applications. Additionally, we offer both Escava DAF (Dissolved Air Flotation) and Clarifier systems for more advanced separation of suspended solids, sludge and/or oils from wastewater, providing options for basic trade waste uses, right up to large scale Municipal applications. Read more…
